| 1.Main technical specification | |
| Bucket Capacity(m³) | 1.3 | |
| Operating Weight(kg) | 6800 | |
| Bucket Width(mm) | 2200 | |
| Bucket type | Heavy-duty bolt on teeth | |
| Rated Load(kg) | 3000kg (including attachment or bucket) | |
| Wheel base(mm) | 2550 | |
| Track(mm) | 1700 | |
| Driving Mode | Hydraulic converter, four wheel drive | |
| Overall Dimensions(mm) | LxWxH:6800x2200x2900 | |
| Lifting to bucket hinge pin Height(mm) | 5200 | |
| 2.Engine Details | |
| Model | YUCHAI Turbo Engine | |
| Engine Type | In-line arrangement, water-cooled, four-cycle diesel,turbocharged Engine | |
| Rated Power(kw) | 76 | |
| Rated Speed (rpm) | r/p.min | |
| Optional Engine | WEICHAI / CUMMINS / YUNNEI | |
| 3.Transmission System | |
| Hydraulic converter + gearbox+drive shaft + hub reduction axles | |
| 4.Operating Specifications | |
| Steering System | Articulated Frame with hydraulic power steering | |
| Min Turning Radius(mm) | 4700 | |
| Driving System | Hydraulic converter, four wheel drive | |
| European quick coupling system | |
| Joystick control | |
| 5.Brake System | |
| Service Brake | Safer air assist disc brake braking system | |
| Parking Brake | Hand operated(Disc brakes) | |
| 6.Tire | |
| Model: | 16/70-24 | |
| Width(mm) | 380 | |
| Diameter(mm) | 1075 | |
| Optional Model | 16/70-20 Herringbone tire | |
