Standard configuration: standard bucket with teeth, fully hydraulic torque converter transmission, 92KW Weichai six-cylinder engine, four-link hydraulic pilot, adjustable instrument LCD display, adjustable seat with backrest/armrest, LED cab ceiling light, large Reversing image, high and low beams, four-corner flash, G2 pattern 17.5-25 tires, four-wheel drive, 25 drive axle, 315 gearbox, timer, single handle operation, seat belt, heater, quick change device, boom shock absorption function , bucket angle control function.

Category:
Description

Main technical specification:

1.0 Engine Details
(1) Model: WEICHAI Engine
(2) Engine Type:In-line arrangement, water-cooled, 6-cycle diesel,turbocharged Engine
(3) Rated Power:92KW
(4) Rated Speed:2400 r/p.min (rpm)
(5)Optional Engine: same with offer sheet
2.0 Transmission System
Hydraulic converter + gearbox+drive shaft + hub reduction axles
3.0 Bucket
(1) Bucket Capacity: 1.7m³
(2) Bucket width: 2300mm
(3) Bucket type:Heavy-duty bolt on teeth
(4) Rated Load: 3500kg including attachment or bucket
4.0 Overall Dimensions
(1) Overall Length: 7000mm
(2) Overall Height:2900mm
(3) Overall Width: 2300mm
(4) Max. lifting Height:6500mm
(5) Lifting to bucket hinge pin Height: 6000mm
5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 5900mm
(3) Driving System: Hydraulic converter, four wheel drive
(4) European quick coupling system
(5) Joystick control
6.0 Brake System
(1) Service Brake:Safer air assist disc brake braking system
(2) Parking Brake:Hand operated（Disc brakes）
7.0 Tire Model:17.5-25

8.0 Wheelbase: 2430mm
9.0 Track: 1700mm
10.Operation weight :8500KG
