SVH80 800KG
Gasoline Honda 390 /9.7kw
Diesel Changchai 186/6kw
Drum diameter width 355*620
Speed 4km/h Excitation force 2 tons
American Danfoss drive motor Japanese NSK bearing
One-button vibration Electromagnetic clutch vibration
With forced forward switch Operating weight 800kg
Working width 680mm
2500*680*1140
Description
Shipping & Delivery
Related products
SVH50 550KG
Gasoline Honda 270/6.7kw
Diesel Changchai 178/4.4kw
Diesel Changchai R180/5.7kw
Steel wheel specifications (width*diameter) 600*426mm
Travel speed 3.8km/h Speed 3600rpm
Climbing grade 30 degrees Cooling system Air cooling (50S is water cooling)
Hydraulic motor drive Excitation force 2 tons
Frequency 70HZ Working weight 550KG
Fuel tank capacity 5.9L/2.7L/6.5L
Plastic packaging size 1650*850*1900mm
ST1200/1000kg
Diesel Changchai 186/6kw
Gasoline Honda 390/Britton Pioneer 400/9.6kw
Drum specifications (width*diameter) 700*500mm
Speed 0-5km/h Air-cooled cooling system
Climbing 30 degrees Excitation force 2.5 tons Continental hydraulic pipe
American Danfoss hydraulic drive motor Dual drive single shock
American Sauer hydraulic pump Vibration frequency 70HZ
Fuel tank capacity 5.5L/6.5L Water tank capacity 65L
Dimensions 1870*830*1985
Operating weight 1000KG
SVH70 850kg
Diesel Changfa 180/4.8kw
Gasoline Honda 390/9.7kw
Wheel specifications (width*diameter) front wheel 700*530
Rear wheel 500*425 Travel speed 0-5km/h
Cooling system Air cooling Climbing grade 30 degrees
Excitation force 2.5 tons Drive system
Front wheel drive Rear wheel steering
Frequency 70HZ Vibration system Electromagnetic clutch
Hydraulic oil radiator
(The only one of the same model in China)
Fuel tank capacity 3.5L/6.5L Water tank capacity 18L
Plastic packaging size 1730*930*1280mm
Working weight 800KG
ST4000/4ton
Diesel Changchai ZN390/28.5kw
Diesel Yanmar 3TNV88/Kubota V1505/28.1kw
Diameter width 720*1200 Changchai 390B
3-cylinder water-cooled diesel engine Nissan NSK bearing
French Poclain drive motor
American Sauer vibration motor
Italian hydraulic pump electronic sprinkler
One-piece vibration dual-drive single/double vibration free adjustment
Full hydraulic excitation force 5 tons 2480*1370*2670
SVH700 550KG
Gasoline Honda 270/6.7kw
Diesel Changchai 178/4.4kw
Drum specifications (width*diameter) 700*530mm
Travel speed 3.8km/h
Speed 3600rpm Climbing grade 30 degrees
Cooling system Air cooling Hydraulic motor drive
Excitation force 2.5 tons Water tank capacity 20L
Frequency 70HZ Working weight 550KG
Fuel tank capacity 3.6L/2.7L
Working weight 550KG
Plastic packaging size 1200*920*1920mm
